Specifications

Adopt stainless-steel and argon arc chamber, high quality steel plate outside the chamber and nice in appearance.The outside door made up of the large and visual angle safety glass of vacuum makes observation easy and clear.Microprocessor temperature and time controller ensure a precise and reliable control, setting up and adjusting through the touch-keyboard.

Drying oven (Hot-air Sterilizer) is applicable for drying, cure, melting and sterilization in dustily and mining enterprises, laboratories and scientific research institutes.

Parameter/Type	DHG-9050B (101-OB)	DHG-9070B (101-1B)	DHG-9140B (101-2b)	Dhg-9240B (101-3B)	DHG-9420B	DHG-9620B
Nominal capacity	50L	70L	140L	240L	420L	620L
Mains voltage	-220V 50HZ
Temperature control scope	RT+10℃—300℃
Temperture resolutionl	0.1℃
Temperature fluctuation	±1℃
Temperature uniformity	±3%(Test point is 100℃)
Working Temperature	+5℃—40℃
Power input	800W	1100W	1300W	1600W	3500W	4000W
Interior Dimension(mm)	350x350x350	450x400x450	550x450x550	600x500x750	590 x 580x1300	590x800x1310
Outline size(mm)	650 x 570 x 540	740 x 520 x 630	840x510x730	890x620x930	900 x 800x1510	900x1020x1500
Working time	1—9999m in

Performance Parameter (no-load testing):Ambient temperature 20℃; Ambient humidity 50%RH.
