It is mainly applied to the measurement of the whiteness of objects or powders with non-colored surface smoothness, and can accurately obtain the whiteness value consistent with the visual acuity.
The paper's opacity can be accurately measured. This item can be widely used in textile printing and dyeing, paint coatings, chemical building materials, paperboard, plastic products, white cement, ceramics, enamel, talcum powder, starch, flour, salt, detergents, cosmetics and other substances whiteness measurement.
|
Measuring Range |
0～120 |
Measuring Condition |
45/0 |
|
Illuminant |
D65 light source |
Show system |
LCD screen |
|
WhitenessMean |
R457 Blu-ray brightness |
Minimum Readout |
0.01 |
|
Calibrate |
φ30 |
Zero Draft |
≤±0.1 |
|
Basic Error |
≤±1 |
Repeatability |
≤0.2 |
|
Power Supply |
AC 220V/50Hz 35W |
External Dimension |
325×265×280mm |
Data storage and query function, automatic calibration.
RS232 data communication interface, printer connection.
