Overview
The MB25 provides precise moisture content determination at an unbeatable value. With a large backlit LCD display, standard RS232 port, 110g capacity with a readability of 0.005g/0.05% and halogen heating, the MB25 offers moisture analysis for any budget.
Applications
Percent Moisture Determination, Percent Solid Determination, Weighing
Display
Backlit liquid crystal display (LCD)
Operation
Power cord (included)
Communication
RS232 (included)
Construction
Halogen heat source, ABS housing, metal pan support, metal pan handler, in-use cover
Design Features
3 shut off criteria (manual, timed or auto), 1 standard heating profile, 50° to 160° C heating range (5° C increments)
Specifications
|
Maximum Capacity |
110 g |
|
Readability Moisture Content |
5 mg/0.05% |
|
Pan Size |
3.5 in (90 mm) |
|
Heater Type |
Halogen Lamp |
|
Communication |
RS232 (Included) |
|
Dimensions (HxLxW) |
5 in x 11 in x 6.5 in (127 mm x 280 mm x 165 mm) |
|
Display |
LCD, backlight |
|
In-use cover |
Included |
|
Net Weight |
5 lb (2.1 kg) |
|
Power |
AC Power (Included) |
|
Automatic - Preset Weight Loss/Time; Timed; Manual |
|
|
Temperature Range |
50 °C – 160 °C |
|
Units of Measurement |
Gram |
|
Working Environment |
50°F – 104°F, 80%RH, non-condensing (10°C – 40°C, 80%RH, non-condensing) |
