Overview
After more than a century of perfecting the art of measurement through our durable weighing products, OHAUS precision is now available in the form of a portable pH meter. This portable meter offers convenience, reliability and durability in one compact design.
Applications
pH, oxidation-reduction potential (ORP) measurement
Display
Liquid crystal display (LCD)
Operation
4 AAA batteries (included)
Communication
N/A
Construction
ABS housing, wrist strap
Design Features
Automatic and manual temperature compensation, auto buffer recognition, calibration icon
Specifications
|
Measurement Range |
0.00 – 14.00 pH; -1999 – 1999 mV; 0 – 100 °C |
|
Accuracy |
±0.01 pH; ±1 mV; ±0.5 °C |
|
Measurement Resolution |
0.01 pH; 1 mV; 0.1 °C |
|
Display |
LCD |
|
Electrode |
ST320 (Included) |
|
Accuracy ± (mV) |
1 mV |
|
Accuracy ± (Temperature) |
0.5 °C |
|
Battery Life |
500 Hours with Disposable Batteries |
|
Calibration |
3 Point |
|
Dimensions (HxLxW) |
1.38 in x 6.69 in x 3.54 in (33 mm x 170 mm x 90 mm) |
|
In-use cover |
No |
|
Measurement Range (Temperature) |
0 °C – 100 °C |
|
Measurement Range |
-1,999 mV – 1,999 mV |
|
Net Weight |
0.16 kg |
|
Parameter |
pH / ORP |
|
pH accuracy (±) |
0.01 |
|
pH measuring range |
0 – 14 |
|
pH resolution |
0.01 |
|
Power |
4 AAA (LR03) Batteries (Included) |
|
Resolution (Voltage) |
1 mV |
|
Temperature Compensation |
Automatic |
|
Temperature resolution |
0.1 °C |
|
Temperature Sensor |
30 KΩ NTC |
|
Working Environment |
41°F – 104°F, 80%RH, non-condensing (5°C – 40°C, 80%RH, non-condensing) |
