pH Mode:
? High precision benchtop pH/Ion meter is equipped with a large backlit LCD display.
? 1 to 5 points calibration with auto-buffer recognition.
? Selectable pH buffer standard (USA/NIST/DIN) or using the custom calibration solutions.
? Automatically calculates and displays electrode slope that helps you decide whether to
replace pH electrode.
ORP Mode:
? Single point offset calibration allows adjusting the displayed value to a known standard.
? Relative and absolute millivolt measurement modes provide accurate ORP readings.
Ion Mode:
? 2 to 5 points calibration including the eight concentration calibration points can be selected.
? Automatically recognize ion selective electrodes, does not need to specify the type of ion.
? Direct ion concentration readout simplifies the elaborate measurement process.
? Selectable multiple concentration units include the ppm, mg/L, mmol/L and mol/L. Other Features:
? Automatic Temperature Compensation ensures accurate reading over the entire range.
? Calibration Due Reminder prompts user to calibrate the meter regularly.
? Stability indicator automatically shows current measurement status.
? Auto-Hold function freezes stable measured value for easy viewing and recording.
? Manual temperature calibration improves the measurement accuracy of meter.
? Selectable temperature unit (°C or °F) meets different application requirements.
? Automatic electrode diagnosis shows zero point offset and slope of the electrode.
? Help message as a operational guide that helps you quickly begin using the meter.
? System menu allows the setting 10 parameters, including the pH buffer standard, number
of calibration points, resolution, stability condition, hold function, etc.
? Reset feature automatically resumes all parameters back to factory default options.
? Expanded memory stores and recalls up to 500 readings.
? Built-in real-time clock stamps stored data to meet GLP standard.
? Stored data can be transferred into computer by USB communication interface.
Specifications
|
Model |
Bante930 |
|
|
pH |
||
|
Range |
-2.000~20.000pH |
|
|
Accuracy |
±0.002pH |
|
|
Resolution |
0.1, 0.01, 0.001pH |
|
|
Calibration Points |
1 to 5 points |
|
|
Calibration Solutions |
USA, NIST, DIN or User-defined |
|
|
mV |
||
|
Range |
-1999.9~1999.9mV |
|
|
Accuracy |
±0.2mV |
|
|
Resolution |
0.1, 1mV |
|
|
Calibration Points |
1 point (Only for Relative mV mode) |
|
|
Calibration Range |
±200mV |
|
|
Ion |
||
|
Range |
0.001~19999ppm, mg/L, mol/L (Refer to the range of ISE) |
|
|
Accuracy |
±0.5% F.S (Monovalent), ±1% F.S (Divalent) |
|
|
Resolution |
0.001, 0.01, 0.1, 1 |
|
|
Calibration Points |
2 to 5 points |
|
|
Calibration Solutions |
0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000ppm, mg/L, mol/L |
|
|
Temperature |
||
|
Range |
0~105°C, 32~221°F |
|
|
Accuracy |
±0.5°C, ±0.9°F |
|
|
Resolution |
0.1°C |
|
|
Calibration Points |
1 point |
|
|
Calibration Range |
Measured value ±10°C |
|
|
Others |
||
|
Temperature Compensation |
0~100°C, 32~212°F |
|
|
Compensation Mode |
Manual or Automatic |
|
|
Hold Function |
Manual or Automatic |
|
|
Stability Conditions |
Low or High |
|
|
Calibration Due |
0 to 31 days |
|
|
Power Off |
Manual or Automatic (10, 20, 30 minutes) |
|
|
Reset Function |
Yes |
|
|
Memory |
Stores up to 500 data sets |
|
|
Output |
USB Communication Interface |
|
|
Connector |
BNC |
|
|
Display |
LCD (130×110mm) |
|
|
Power Requirements |
DC5V, using AC adapter, 220VAC/50Hz |
|
|
Dimensions |
210(L)×188(W)×60(H)mm |
|
|
Weight |
1.5kg |
Order Information
|
Order Code |
Accessories |
|
Bante930-CN |
E201-BNC pH Electrode |
|
TP-10K Temperature Probe |
|
|
pH Buffer Pouches (pH4.01/7.00/10.01) |
|
|
USB Cable |
|
|
DC5V Power Adapter |
|
|
Bante930-UK
|
P11 Glass pH Electrode (Made in UK) |
|
TP-10K Temperature Probe |
|
|
pH Buffer Pouches (pH4.01/7.00/10.01) |
|
|
USB Cable |
|
|
DC5V Power Adapter |
Optional Accessories
|
Items |
Description |
|
For the general liquids |
|
|
For the non-aqueous samples |
|
|
For the photographic processing solutions |
|
|
For the biofuel |
|
|
For the low ionic strength samples |
|
|
For the sample in the test tube |
|
|
For the micro-volume samples |
|
|
For the outdoor applications |
|
|
For the low conductivity liquids |
|
|
For the Tris buffers |
|
|
For the semisolid samples (Flat Surface) |
|
|
For the slurries |
|
|
For the semisolid samples |
|
|
For the colloids |
|
|
For high temperature measurements |
|
|
For the sample with strong redox potential |
|
|
For the sample with weak redox potential |
|
|
Range: 0.1~23000ppm |
|
|
Range: 1.8~35500ppm |
|
|
Range: 0.02ppm to Saturation |
|
|
Range: 0.02~40000ppm |
|
|
Range: 0.4~62000ppm |
|
|
Range: 0.4 to 79900ppm |
|
|
Range: 0.1~18000ppm |
|
|
Range: 0.2~260ppm |
|
|
Range: 0.01~11200ppm |
|
|
Range: 0.006~6400ppm |
|
|
Range: 0.06~127000ppm |
|
|
Range: 0.2~20700ppm |
|
|
Range: 0.01~107900ppm |
|
|
Range: 0.04~39000ppm |
|
|
Range: 0.003~32100ppm |
|
|
Range: 0.02~17000ppm |
|
|
480mL/Bottle |
|
|
480mL/Bottle |
|
|
pH4.01/7.00/10.01 |
|
|
pH4.01/6.86/9.18 |
|
|
Special-purpose sensor |
Packaging
|
Order Code |
Dimensions |
Weight |
|
Bante930-CN |
310(L)×240(W)×180(H)mm |
1.7kg |
|
Bante930-UK |
310(L)×240(W)×180(H)mm |
1.7kg |
