1.It functions as automatic and manual temperature compensation.
2.If matched with the titanium alloy sensor of 0.01cm-1 and sealed measuring reservoir, it can test high purity water.
3.It is equipped with DJS-1C conductancesensor (platinum black) and T-818-B-6 temperature sensor.
1.Measuring range:
Conductivity: 0.00μS/cm~100μS/cm
TDS:0~1000 mg/L
Temperature: 0.0~60.0 ℃
2.Accuracy:
Conductivity: ±0.5%FS
T D S:±1.0%FS)
Temperature: ±0.3℃±1 bit
3.Stability: (±0.33%FS±1 digital)/3h
4.Temperature compensation range: Manual/Automatic (0.0~40.0))℃
5.Temperature compensation coefficient: 2%
6.Power supply: AC(220±22)V;(50±l)Hz
7.Dimension(mm):300×200×72
8.Net Weight: 1.5kg
9.Case outside serial No: WXS-A008-1
Package Size: 610X290X640mm
Gross Weight: 2.5 kg
Conductance Constant and corresponding Conductivity measuring range:
Electrodeconstant (K) (cm-1) |
0.01 |
0.1 |
1 |
10 |
Measuring range (μS/cm) |
0.0~2.0 |
0.2~20.0 |
2~1×104 |
1×104~1×105 |
