OUTFIT |
MODEL |
|
|
XSZ-2108A |
||
|
Optical System |
UIS(Universal optical system) |
○ |
|
Illumination |
Epi-kohler illumination 6V20W,Halogen lamp 100-240V 50/60Hz |
○ |
|
Focusing |
Stage height adjustment mechanism Fine adjustment Scale:0.001mm per turnCoaxial Coarse range 14mm |
|
|
Nosepiece |
Quadruple |
○ |
|
Viewing Head |
Binocular Head,inclined at 30°Interpupillary distance 48-75mm |
○ |
|
Stage |
Size:140x140mm, moving range 75x45mm |
○ |
|
CondenserNA=1.25 |
Abbe Condenser, NA=1.25(when immersed in oil) |
○ |
|
Obiectives |
Plan-achromatic |
○ |
