OUTFIT

MODEL

XSZ-2007

Achromatic Objectives

4X、10X、40X ( S ).100X( S, Oil )

○

20X

Wide Field Eyepiece

WF10X、(WF16X for choice)

○

Sliding Binocular Head

Inclined at 45? , 360? Rotatable
Interpupilary Distance 55～75mm

○

Sliding Trinocul ar Head

Nosepiece

Quadruple

○

Quintuple

Double layer Mechanical stage

Size 140x140mm，Moving Range 75x45mm

○

Focusing

Coaxial Coarse and Fine Adjustment, Focusing Range 30mm, Focusing Interval 0.002mm

○

Illumination, condenser
NA=1.25

6V/20W Halogen Lamp, Adjustable Brightness

○

Kohler Illumination

Power

AC Input 220V or 110V, DC Output 6V

○
