Length of jacket | Ground mouth | Cooling area | Total length |
(mm) | (dm2) | (mm) | |
80 | 10/19 | 0.16 | 165 |
80 | 14/23 | 0.16 | 175 |
150 | 14/23 | 0.6 | 254 |
200 | 14/23 | 1 | 305 |
200 | 19/26 | 1 | 332 |
200 | 24/29 | 1 | 350 |
200 | 29/32 | 1 | 360 |
300 | 19/26 | 1.6 | 432 |
300 | 24/29 | 1.6 | 450 |
300 | 29/32 | 1.6 | 460 |
400 | 19/26 | 2.1 | 535 |
400 | 24/29 | 2.1 | 555 |
400 | 29/32 | 2.1 | 560 |
500 | 19/26 | 2.7 | 632 |
500 | 24/29 | 2.7 | 650 |
500 | 29/32 | 2.7 | 660 |
600 | 19/26 | 3.2 | 735 |
600 | 24/29 | 3.2 | 735 |
600 | 29/32 | 3.2 | 760 |
