(1) Wide application range and easy-to-operate feature.
(2) Measure reflection color and transmission color of objects and can test chromaticity, whiteness and color difference between two objects or two kinds of liquid.
(3) Only accept d/0 lighting specified by CIE.
(4) Display reflectance and transmittance of objects or liquid within the scope of visible light wave (380nm-760nm), and generate a spectral curve on reflectance and transmittance of objects or liquid, which greatly facilitates analysis on object color.
(5) Wide used in such industries as textile, dye, printing and dyeing, coating, paint, paper making, building materials, food, and printing.
(1) Lighting conditions: d/8
(2) Light source: pulsed-xenon lamp
(3) Receiver: photodiode array, flat fielding grating
(4) Spectrum conditions: overall response is equivalent to tristimulus values X, Y, and Z calculated in corresponding functions under GB3978 standard illuminant D65, A, C and 10°, 2° view of field.
(5) Display method: computer display screen
(6) USB
(7) Measurement window: ?20mm
(8) Wavelength range: 380nm~760nm
(9) Total uncertainty of wavelength (nm): 1
(10) Wavelength repeatability (nm): 0.2
(11) Total uncertainty of spectrum transmittance (%): 0.5
(12) Repeatability of spectrum transmittance (%): 0.2
(13) Total uncertainty of spectrum reflectance (%): 1.0
(14) Repeatability of spectrum reflectance (%): 0.4
(15) Instrument stability: ΔY≤0.2
(16) Instrument repeatability: ΔY≤0.2；ΔE≤0.02 (standard white board, mean of 10 measurements)
(17) Total uncertainty of colorimetry: ΔY≤1 Δx, Δy≤0.002
Palette system:
Color: X, Y, Z; Y, x, y; L*, a*, b*; L, a, b; L*, u*, v*; L*, c*, h*
Color difference: Δ E (L*a*b*); ΔE (Lab); ΔE (L*u*v*); ΔL*, ΔC*, ΔH*
Whiteness: W, T
Computer system: Pentium 4 or above
Software: WSF-J dedicated software, under Windows XP or 2000 operating system
Weight (Gross): 24kg
Overall dimensions: 680mm ? 430mm ? 430mm
