To be used in production of medicines, dye-stuffs, perfumes and other organic crystal substances.
Together with Visual window and Photoelectric test
Use PID to control the temperature
It can measure three samples at the same time and calculate average value of initial and final melting points automatically.
Touch Screen
USB and RS232
Melting-point measurement range: room temperature -320 C
Minimum digital display: 0.1 C
Size of the capillary: φ1.4mm(outside diameter)φ1.0mm(inside diameter), 100mm
Loading height of the sample: 3mm
Linear heating-up rate: 1.0 C /min （0.2 C/min；1.5 C/min；3 0 C/min）
Accuracy: when the environmental temperature is 23 C 5C:
< 200 C : 0.5C; 200-320 C: 0.8C
Deviation of linear heating rate: no more than 10% (setting value)
