This type of viscometer covers the index of the current market from STM-1 to STM-4
No need of counterweight or glide wheel , which simplifies the testing program
Electrical lifting design that reduces the requirement of testing liquid level control
Agrees with the industrial paint standard ASTM D562, GB9269
The stepping motor drives directly without gear at an accurate rotational speed
The LCD screen shows a lot of information in blue lighted background
The viscometer is able to lock the viscosity value, KU value, load value and temperature
Shows the continuous variation of viscosity value
Alarm alerts when the measurement is out of range
Standard RTD temperature sensor
Equipped with the printing port of automatic testing data output
Linear correction for the whole measurement by the computer
AC adaptor 100V- 240V, excellent in interference immunity
|
Type |
STM-2 |
|
Measurement Range (mPa.s) |
40 KU -141 KU, 32g – 1099 gm , 27-5274 cp |
|
R.P.M (per min) |
200RPM |
|
Container |
1 Pint |
|
Rotor Amount |
KU 1 -10 |
|
Measurement Accuracy |
+ - 1.0 % (of the full range) |
|
Repeatability |
0.5% |
