Characteristics:
Standard scanning software can directly complete functions of Quantitative; Kinetics; Wavelength Scan; Multi Wavelength; DNA/Protein and Data processing.
Can establish calibration curves and implement associated tests. The instrument internal can be stored 200 groups of data and 200 standard curves.
- Suspended posture optical system design, strengthen and thicken the bottom plate to eliminate the vibration or transformation’s impact on the optical system.
- Automatic wavelength calibration and automatic deviation repair.
- Tungsten lamp can be changed easily, without debugging.
- Standard with PC software
| Wavelength Range | 320-1100nm |
| Bandwidth | 2nm |
| Wavelength Accuracy | ±0.5nm |
| Wavelength Reproducibility | ≤0.2nm |
| Photometric Accuracy | ±0.3%T |
| Photometric Repeatability | ≤0.15%T |
| Straylight | ≤0.05%T |
| Stability | ±0.0001A/h(500nm) |
| Baseline Flatness | ±0.0001A/h |
| Noise | ±0.0005A |
| Photometric Range | 0-200%T, -0.3--3A, 0-9999C |
| Wavelength setting mode | Automatic |
| Scanning speed | HI,LOW,Optional |
| Output | USB Port |
| Printer port | Parallel Port |
| Display | Graphic LCD(128*64) |
| Light Source | Tungsten Halogen Lamp |
| Detector | Silicon Photodiode |
| Power | AC 220V/50Hz or 110V/60Hz |
| Dimension | 460x380x180mm |
| Weight | 15Kg |
