Product name |
Vertical shaker |
Horizontal shaker |
Horizontal shaker |
Multi-shaker |
|
Model |
HY-1 |
HY-2 |
HY-2B |
HY-3 |
|
Motion type |
Vertical |
reciprocating |
reciprocating |
Vertical & reciprocating |
|
Clamp type |
Flask clip |
holding tap funnel |
Nip roll style |
multi-use spring |
|
Speed range |
Start up-300rpm |
Start up-300rpm |
: Start up-300rpm |
Vertical : Start up-200rpm Reciprocate: Start up-300rpm |
|
Amplitude size |
20mm |
20mm |
20mm |
Vertical :15mm Reciprocating:20mm |
|
Timer |
0~120 minutes(or with no limit) |
|||
|
Voltage |
110V 60Hz /220V 50Hz |
|||
|
Dimension(mm) |
620×520×390 |
390x320x200 |
420x320x300 |
740x450x340 |
|
Weight |
16kg |
13.5kg |
16kg |
19kg |
|
Product name |
Reciprocate shaker |
Reciprocate shaker |
Orbital shaker |
Orbital shaker |
|
Model |
HY-4 |
HY-4A |
HY-5 |
HZ-82 |
|
Motion type |
reciprocating |
reciprocating |
Orbital |
Orbital |
|
Working size(mm) |
400x270 |
400x270 |
420x320 |
420x320 |
|
Speed display |
----- |
Yes |
----- |
Yes |
|
Clamp type |
multi-use spring |
|||
|
Speed range |
Start up-300rpm |
|||
|
Amplitude size |
20mm |
|||
|
Timer |
0~120 minutes(or with no limit) |
|||
|
Voltage |
110V 60Hz /220V 50Hz |
|||
|
Dimension(mm)(mm) |
400x270x200 |
400x270x200 |
430x320x230 |
430x320x230 |
|
Weight |
12kg |
12.5kg |
15kg |
16kg |
