●Hand wheel type of quick-open door structure
●Mechanical safety interlocking device
●Computer control auto recycle sterilization
●LED screen indicate working state
●Temperature scope 50℃-126℃
●Time scope 0-9999min
●Automatic shut down with beep reminding after sterilization
●Fully stainless steel
|
Model |
LDZX-40B |
LDZX-50B |
LDZX-75B |
LDZX-100B |
|
Capacity |
40L |
50L |
75L |
100L |
|
Sterilization room size |
Ф340×425mm |
Ф340×525mm |
Ф380×530mm |
Ф500×560mm |
|
Maximum pressure |
0.145-0.165Mpa |
0.145-0.165Mpa |
0.145-0.165Mpa |
0.145-0.165Mpa |
|
Maximum temperature |
126℃ |
126℃ |
126℃ |
126℃ |
|
Maximum timer |
9999min |
9999 min |
9999 min |
9999 min |
|
Heating power |
3.5KW |
3.5KW |
4.5KW |
6.0KW |
|
Power supply |
220V 50Hz |
220V 50Hz |
380V 50Hz |
380V 50Hz |
|
Dimension(mm) |
510x510x1200 |
510x510x1250 |
570x570x1300 |
600×600×1360 |
|
Weight |
55kg |
58kg |
77kg |
120kg |
