Specifications

Rectangle shape, the casing of this serial of resistance furnace is made up of excellent steel plates and soldered in hems.The work room is made up with flame-proofing materials manufactured into bulk encasing hearth with inlaid heating elements. Between the hearth and casing are the fire resistant and thermal insulation materials.Under the furnace mouth, there is safety switch interlocking with the furnace door, which will automatically cut off the power supply when furnace door opened to ensure safety.

The apparatus can be used in laboratory, enterprise of industrial and mining, scientific research institute for testing elements and quenching, annealing and tempering of small steel by heating. High temperature furnace can be used in metals, ceramic material for heating, melting and analysis by heating.

Parameter/Type	SX2-2.5-10	SX2-4-10
Rated power(KW)	2.5KW	4KW
Rated Voltage(V)	-220V 50HZ
Rated temperature	1000°C
Phase	single
Interior dimension(mm)	200x120x80	300x200x120
Outline size(mm)	540x370x470	660x450x540
Net/gross weight(kg)	55	75
